- Self-suction - self-priming. Eccentric of self-adjusting blades
- With recirculation bypass
- Suction: 2.7 m · Delivery: 20 m
- Priming pipe suction: 5 m
- Free flow: 50 l/min
- Consumption: 18-24 A (12 VDC) and 9-17 A (24 VDC)
- Motor: 0.30 kW (12 and 24 VDC) self-ventilated · dust protected
- S2 30´ duty
- 3,000 rpm
- Bypass pressure: 1.2 bar
- Connection through F1" (BSP) threads and flanges
- It has built in a cleaning steel filter of 350 µm (micron).
- ON/OFF luminous switch with IP-55 protection
- 2 m cable with clamps
- Anti-rust treatment
Size and weight (approx.):
- Dim.: 160x200x137 mm (length x width x height)
- Weight: 4.5 kg
