MGI-250 F 11/2" BSP Gear Pulser

Pulser for its in-line assembly, making easier the exact information of the fluid management and control systems.

 Technical data:

• Flow (approx.):
  • 10-250 l/min (diesel)
  • 10-150 l/min (lubricant
• Viscosity: 2-2000 cSt
• Voltage: 28 VDC
• Max. power: 8 W
• Maximum current: 100 mA
• Accuracy: ±0.5%
• Maximum pressure: 45 bar
• Min./max. temperature with Reeds: -10ºC / +90ºC
• Two channels: 11 pulses per litre and channel
• Inlet / outlet connection: F1" or 1 1/2" BSP (flange)
• Housing and cover: Aluminium

Size and weight (approx.):

• Dim.: 183x100x141 mm (length x width x height)
• Weight: 2.5 kg
